Stainless Steel Fiber Laser Engraving Machine
PL-M30S fiber laser marking machine configured for stainless steel: 30W Raycus or JPT source, 1064 nm wavelength, 0.02 mm minimum line width and 130-150 ns pulse width.
Overview
The PL-M30S is set up specifically for stainless steel, where the mark has to survive passivation, handling and cleaning. A 30 W Raycus or JPT source produces a 0.02 mm minimum line width, and the 130–150 ns pulse width gives a clean, oxidation-controlled mark on 304 and 316 grades.
The 1064 nm wavelength is absorbed well by stainless steel, so marking is fast and repeatable without pre-treatment. It suits parts that need traceability marking — batch numbers, serials, logos — carried through the rest of the production process.
Technical Specifications
| Machine configuration | ||
| Model | PL-M30S | |
|---|---|---|
| Dimensions and weight | 62 × 44 × 40 cm, gross weight 25 kg. | |
| Laser source and optics | ||
| Laser power | 20 W | 30 W |
| Wavelength | 1064 nm +/- 4 nm | |
| Laser source | Raycus Fiber Laser or JPT laser | |
| Minimum line width | 0.02 mm | |
| Pulse width | 110–140 ns | 130–150 ns |
| Single pulse energy | 0.67 mJ | 0.75 mJ |
| Beam diameter | 7 ± 1 | |
| Frequency adjustment | 30–60 kHz | 40–60 kHz |
| Marking speed | ≤7000 mm/s | |
| Power control | 10–100 % | |
| Marking area | 110 × 110 mm / 150 × 150 mm / 175 × 175 mm / 200 × 200 mm | |
| Focus system | Double red light pointer assist for focal adjustment | |
| Cutting and engraving performance | ||
| Cutting thickness | 0–0.2 mm | 0–0.5 mm |
| Power, cooling and environment | ||
| Cooling | Air cooling | |
| Power supply | 220 V ± 10 % (110 V ± 10 %) / 50 Hz 60 Hz compatible | |
| Other specifications | ||
| M2 | <1.5 | <1. 6 |
Key Features
- Tuned for stainless steel marking
- 30 W Raycus or JPT source
- 1064 nm ± 4 nm wavelength
- 0.02 mm minimum line width
- 130–150 ns pulse width
Typical Applications
- 304 and 316 stainless steel parts
- Traceability and serial numbering
- Kitchenware and sanitary ware
- Medical and food-grade equipment
Machine Details
